型号 Model |
简体直径 Diameter of The shell (mm) |
简体长度 Length of The shell (mm) |
最大装球量 Max load Of ball (t) |
给料粒度 Feed partice (mm) |
处理能力 Capacity (t/h) |
发动机Motor |
重量 Weight (kg) |
备注 Remarks |
||
|
型号 Model |
功率kw Power |
|||||||||
| MQG(Y)0909 | 900 | 900 | 0.96 | ≤40 | 0.22-1.07 | Y255S-8 | 18.5 | 4400 |
并可根据用户要求加工圆弧齿型USDT官网下载TRC20 Gear Bal Grinders Can Be Manufac T ured Accord Ing to The Require Ments of Custome Rs |
|
| MQG(Y)0918 | 900 | 1800 | 1.92 | ≤40 | 0.44-2.14 | Y255M-8 | 22 | 5890 | ||
| MQG(Y)0932 | 900 | 3200 | 5.5 | ≤40 | 0.8-3.5 | Y280S-8 | 37 | 9000 | ||
| MQG(Y)1212 | 1200 | 1200 | 2.4 | ≤40 | 0.17-4.1 | Y250M-8 | 30 | 11400 | ||
| MQG(Y)1224 | 1200 | 2400 | 4.8 | ≤40 | 0.35-8.2 | Y3159-8 | 55 | 14560 | ||
| MQG(Y)1515 | 1500 | 1500 | 5 | ≤25 | 1.4-4.5 | YR280S-8 | 55 | 13970 | ||
| MQG(Y)1530 | 1500 | 3000 | 10.4 | ≤25 | 2.8-9 | JR125-8 | 95 | 17530 | ||
| MQG(Y)2122 | 2100 | 2200 | 10 | ≤38 | 5-29 | JR137-8 | 155 | 45600 | ||
| MQG(Y)2130 | 2100 | 3000 | 20 | ≤38 | 6.5-36 | JR137-8 | 210 | 49053 | ||
| MQG(Y)2430 | 2400 | 3000 | 22 | ≤25 | 7.2-92 | JR1410-8 | 280 | 67000 | ||
| MQG(Y)2721 | 2700 | 2100 | 23 | ≤25 | 6.5-85 | JR1410-8 | 280 | 69000 | ||
| MQG(Y)2727 | 2700 | 2700 | 29 | ≤25 | 9-110 | JR157-8 | 320 | 73000 | ||
| MQG(Y)2736 | 2700 | 3600 | 39 | ≤25 | 10.5-130 | TDMK400-32 | 400 | 95036 | ||
| MQG(Y)2740 | 2700 | 4000 | 41 | ≤25 | 11.5-140 | TDMK400-32 | 400 | 99727 | ||
| MQG(Y)3230 | 3200 | 3000 | 16 | ≤25 | 65-85 | TDMK630-36 | 630 | 128000 | ||
| MQG(Y)3236 | 3200 | 3600 | 58 | ≤25 | 95-110 | TDMK630-36 | 630 | 137128 | ||
| MQY3245 | 3200 | 4500 | 65 | ≤25 | 110-120 | TDMK630-36 | 630 | 14300 | ||
| MQG3245 | 3200 | 4500 | 65 | ≤25 | 115-145 | TDMK800-36 | 800 | 146522 | ||
| MQY3645 | 3600 | 4500 | 76 | ≤25 | 140-153 | TKMK1000-36 | 1000 | 135000 | ||
| MQG3645 | 3600 | 4500 | 90 | ≤25 | 150-185 | TDMK1250-40 | 1250 | 159700 | ||
| MQY3660 | 3600 | 6000 | 102 | ≤25 | 180-200 | TDMK1250-40 | 1250 | 154000 | ||
| MQG3660 | 3600 | 6000 | 120 | ≤25 | 195-230 | TDMK1600-40 | 1600 | 189000 | ||
| MQG4050 | 4000 | 5000 | 101 | ≤25 | 270 | TDMK1400-40 | 1400 | 230000 | ||
| MQY4050 | 4000 | 5000 | 90 | ≤25 | 250 | TDMK1250-40 | 1250 | 226000 | ||
